Rabbit-shaped Sand Maker Device

The rabbit-shaped sand maker device is a type of impact crusher that has a vertical shaft. There is a rotor on this shaft where spaces are provided for setting up sand-making hammers. Rocks are crushed upon impact with these hammers and thrown towards the inner body. Additionally, these hammers are made from manganese steel or manganese molybdenum steel, based on the type of mineral material.

The useful load production capacity of this device is estimated to be below 30 tons per hour, with input rock sizes up to a maximum of 50 mm. The output size is less than 15 mm (although more than 60 percent of the load is below 6 mm).

The advantages of the rabbit-shaped sand maker include:

• Easy replacement of spare parts
• Easy installation and placement
• Operation with very low vibration

Rabbit-shaped Sand Maker Device

The rabbit-shaped sand maker is another type of impact crusher device. In impact crushers, the impact force breaks and crushes materials, rocks, and minerals. Unlike other impact crushers, the rabbit-shaped impact crusher has a vertical axis, and the rotor rotates around this vertical axis.

Indeed, sand makers are part of crushers used in mines that prefer to produce more crushed sand. Sand makers have various capacities and capabilities, including the ability to crush dry non-sticky materials with strength up to 450 MPa. Sand makers are built and produced in three models: Rabbit-shaped, Bucket-shaped, and Rock and Rock, and then offered to the market for consumers to use.

The rotor’s rotation around the vertical axis in the rabbit-shaped sand maker creates centripetal force. This force causes the rock fragments to be flung towards the walls, ultimately crushing them. The rabbit-shaped sand maker is more useful for softer materials and is used in various industries.

Functioning of the Rabbit-shaped Sand Maker Device

The rabbit-shaped sand maker is a type of impact crusher that has a vertical shaft. A rotor is placed on this vertical shaft. The placement of this rotor is such that there is space to install hammers on it. The presence of hammers is essential to apply the force generated from rotation to the materials and impurities that are introduced for crushing within the device.

Due to the rotor’s rotation in the rabbit-shaped sand maker and the collision of materials and rock fragments with hammers, these materials and fragments are thrown towards the device’s interior walls, thus accomplishing the crushing process. In the sides and internal walls of the device, anvils are installed that the incoming rock fragments are thrown toward. This sand maker is manufactured in two forms: thick shaft T800 and thin shaft S800.

Features of the Rabbit-shaped Sand Maker

The input materials and rocks entering the rabbit-shaped sand maker should be between 20 to 50 mm in size, and this device performs better with softer materials. After the crushing process in the rabbit-shaped sand maker, which is conducted using impact force, over seventy percent of the sand produced from this crusher is between 0 to 6 mm in diameter.

However, some believe that the size of the input materials and rock aggregates should not exceed forty millimeters. The shape and model of the aggregates and sand outputs from the rabbit-shaped sand maker are multi-faceted and sharp. The input capacity of the rabbit-shaped sand maker is between 30 to 25 tons per hour from 20 to 50 mm stone aggregates. The weight of this crusher model is about 400 kilograms, and each rabbit-shaped sand maker’s motor has a capacity of around 75 horsepower. The rabbit-shaped sand maker is mostly used for producing sand in specific and fine sizes. After receiving raw materials and input aggregates, this device crushes them into sand at a set percentage. The produced sands have a multi-faceted appearance.

Maintenance of the Rabbit-shaped Sand Maker

One of the most important features of the rabbit-shaped sand maker is its easy installation and replacement of consumable parts. The ease of changing parts, given that the parts can be replaced in the minimum time, increases its efficiency in the industry. Replacing spare parts at the minimum possible time provides peace of mind for consuming industrialists.

For easy maintenance and replacement of spare parts, several side doors are placed on the device. By opening these side doors, access to all internal parts and components of the crusher is possible. To prevent the rabbit-shaped sand maker from vibrating during operation, shock absorbers are installed. This means that the shaft and axis of this crusher are equipped with anti-vibration systems. The installation method of the chassis in this device allows it to be used in three directions for the consumer. The internal hammers installed on the rotor are made of Hadfield steel. The use of Hadfield steel in these hammers makes them resistant to abrasion and gives them anti-wear properties. The rabbit-shaped sand maker’s resistance to wear and the ease of replacing and repairing its internal parts make it a very cost-effective option for consumers.

Price of Rabbit-shaped Sand Maker Crusher Device

The price of the rabbit-shaped sand maker crusher device varies depending on the type and capacity of the device or specific customer requirements and price fluctuations. To order, buy, sell, or produce your desired device, contact our experts at Avangard Company.

Apologies, prices are currently updating. Please contact Avangard’s sales department for price inquiries..
